diamond segment

Product Description

Whirlwind diamond segments for granite cutting is used for cutting various types of stone such as marble, granite, sandstone, jade, microcrystalline stone, artificial stone ceramics etc. It is suitable for wet drilling of various types of reinforced concrete and construction engineering geological drilling. The product has high sharpness and long wear resistance. Concrete grinding segments can be formulated according to the specific requirements of customers. Whirlwind brand is a famous at home and abroad.

Huanghe Whirlwind is a professional diamond segment manufacturer in China, which has over 30 years diamond granite segment production history. Diamond gringding segments of Huanghe Whirlwind are composed of diamond powder and other metal elements. Our marble diamond segment can improve the working condition of the working face, reduce the lateral burden, and improve the cutting speed and drilling quality. Welcome to contact us at any time for free inquiry!

Characteristic

Top Quality, high Sharpness, high cutting speed, high precision and 1.2 times longer lifespan.

Application

Cutting of various kinds of stone such as marble, granite, sandstone, ceramics, concrete etc.

Parameters

Outer Diameter(mm)	Length(mm)	Width(mm)	Height(mm)	SEG.NO/Set	Application
250	40	2.6/2.8	10/15/20	17/18	Cutting of granite, marble, sandstone, limestone, slate, andesite, basalt, concrete and other special materials
300	40	2.8/3.0	10/15/20	20/21
350	40	3.0/3.2	10/15/20	24
400	40	3.4	10/15/20	28
450	40	3.6	10/15/20	32
500	40	3.8/3.6	10/15/20	35
600	40	4.6/4.2	10/15/20	42
700	40	5	10/15/20	50
800	24	5.4	10/15/20	46
1000	24	6.5/7.0	13/15/20	70
1200	24	7.5/6.5/6.6/6.8	13/15/20	80
1300	24	7.2/7.8	13	88
1400	24	7.2/7.8/7.8/8.4	10/15/20	96
1600	24	8.0/8.2/8.4/8.6/9.0/9.2	12/15/20	108
1800	24	9.0/9.2	13/15	120
2000	24	8.5/8.8/9.5	13/15/20	132
2200	24	9.9/10.0/10.6/11.2	15	136
2500	24	10.5/11.5	15	140
2700	24	11/12.2	20	150
3000	24	11/11.2/12.5/13	20/25/33	160
3500	24	12.0/12.2/13.5	20/60	180
*Other specification and sizes are available with customer's specific requirements.
